Manual 37128A GCP-20 Series - Genset Control
© Woodward Page 69/190
Service Display
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
Service display
ON
only visible, while
configuration mode is active
Service display ON/OFF
ON................ The following three screens are displayed (the voltages and frequen-
cies of the busbar, the mains and the generator are displayed). In ad-
dition, the controller outputs and the switching states of the power
circuit breakers during synchronization are displayed. According to
the used hardware (with/without voltage transformer), different
screens are displayed.
OFF.............. The service screens are not displayed.
Synchronous Generator
Sam0000V 00.00Hz
Gen0000V 00.00Hz
only visible, while
configuration mode is active
Double voltage and double frequency display
The generator and busbar voltage and frequency are displayed:
Sam.............. Busbar voltage and frequency
Gen .............. Generator voltage and frequency
Net0000V 00.00Hz
Sam0000V 00.00Hz
only visible, while
configuration mode is active
Double voltage and double frequency display
The generator and busbar voltage and frequency are displayed:
Net................ Mains voltage and frequency
Sam.............. Busbar voltage and frequency
Induction Generator
Remanenz 00.00Hz
Gen0000V 00.00Hz
only visible, while
configuration mode is active
Double voltage and double frequency display
The generator and busbar voltage and frequency are displayed:
Remanence.. Frequency of the remanent voltage (only for induction generators)
Gen .............. Generator voltage and frequency
Net0000V 00.00Hz
Remanenz 00.00Hz
only visible, while
configuration mode is active
Double voltage and double frequency display
The generator and busbar voltage and frequency are displayed:
Net................ Mains voltage and frequency
Remanence.. Frequency of the remanent voltage (only for induction generators)
