Manual 37128A GCP-20 Series - Genset Control
© Woodward Page 127/190
Analog Inputs (Option T4)
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
Parameter 202
Configure
analg.inp. YES
Option T4 only
Configuration of analog inputs YES/NO
Parameters are grouped together in blocks to permit quicker navigation through the
large number of configuration screens. Selecting "YES" or "NO" has no effect if
controlling or monitoring is performed. This parameter has the following effects:
YES.............. The configuration screens in the next block are displayed and can ei-
ther be viewed ("Select" push-button) or modified ("Cursor →",
"Digit ↑" or "Select" push-buttons).
NO................ The parameters in the next block are not displayed, cannot be modi-
fied and are therefore skipped.
Parameter 203
Temperature in:
-------
Option T4 only
Temperature measurement in Celsius / Fahrenheit
A decision is made in this screen whether the temperature measurement of the ana-
log inputs should be in °C or in °F. This applies only to Pt100 measuring inputs or
VDO temperature.
Setting the Analog Inputs
NOTE
The analog inputs [T1] to [T4] are only available in the T4 Option. The following specification for the in-
puts is possible:
• Scaleable analog input 0/4 to 20 mA
• Pt100/Pt1000 input
• VDO input (temperature or pressure)
• PTC input
• External power set point with 0/4 to 20 mA (OptionX)
Analog input 1 2 3 4
Assignment VDO #1 VDO #2 0/4 to 20 mA 0/4 to 20 mA
Terminal 93/94/95 96/97/98 99/100/101 102/103/104
Function Alarm input Alarm input Alarm input
VDO #1 = 0 to 180 Ohm, VDO #2 = 0 to 380 Ohm
