Appendix C.
Analog Output Manager
(Option A2)
NOTE
The functions listed below can only be output correctly if the existing version of the control permits
this.
Func-
tion
Output Value Input of the two limit values
0 The analog output is disabled. N/A N/A
1
Actual generator real power [dimen-
sionless]
0% Lower power limit (can also be
negative) e.g.
–
0050 kW
100% Upper power limit (can also be
negative) e.g. 0200 kW
2
Actual generator power factor ϕ
[e.g. (-070 to +080) /100]
(Definition at end of Table)
[dimen-
sionless]
0% Lower interval to power factor ϕ=1
e.g.
-
0030 corresponds to c0.70
100% Upper interval to power factor ϕ=1
e.g. 0030 corresponds to i0.70
3
Actual generator frequency
[Hz∗100]
0% Lower frequency e.g. 0000
corresponds to 00.00 Hz.
100% Upper frequency e.g. 7000
corresponds to 70.00 Hz.
4
Actual generator reactive power [kvar] 0% capacitive reactive power
(negative) e.g -0100 kvar
100% inductive reactive power
(positive) e.g. +0100 kvar
5
Rated power of all generators
connected to generator busbar
minus nominal actual power
[kW]
6
Total actual power of all genera-
tors connected to generator bus-
bar
[kW]
0% Lower power (can also be
negative) e.g.–0050 kW
100% Upper power (can also be
negative) e.g. 0200 kW
7
Generator apparent current in L1 [A]
8
Generator apparent current in L2 [A]
9
Generator apparent current in L3 [A]
0% Lower current output
e.g. 0000 A
100% Upper current output
e.g. 500 A
