Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
Page 156/190 © Woodward
Func-
tion
Output Value Input of the two limit values
10
Speed via Pickup [min
-1
] 0% Lower speed
e.g. 0000 rpm
100% Upper speed
e.g. 3000 rpm
11
Analog input [T1] [°C] or
[°F] or
freely scaleable
12
Analog input [T2] [°C] or
[°F] or
freely scaleable
13
Analog input [T3] [°C] or
[°F] or
freely scaleable
14
Analog input [T4] [°C] or
[°F] or
freely scaleable
15
--inactive--
16
--inactive--
17
--inactive--
18
Additional freely scaleable ana-
log input (terminals 91, 92)
[°C] or
[°F] or
freely scaleable
0% Lower measured value
e.g. 0000 corresponds to 000 °C
at temperature input
100% Upper measuring value
e.g. 0255 corresponds to 255 °C
at temperature input
0% Lower measured value e.g. 0000
corresponds to 00.0 bar oil pressure
100% Upper measured value e.g. 0100
corresponds to 10.0 bar oil pressure
19
Actual mains interchange (im-
port/export) real power
[kW] 0% lower power
e.g. -0800 kW
100% upper power
e.g. 0800 kW
20
Mains apparent current in L1 [A] 0% Lower current output
e.g. 0000 A
100% Upper current output
e.g. 500 A
21
Mains power factor ϕ
[e. g. (-070 to +080) /100]
(Definition at end of Table)
[dimen-
sionless]
0% Lower interval to power factor ϕ=1
e.g. -0030 corresponds to k0,70
100% Upper interval to power factor ϕ=1
e.g. 0030 corresponds to i0,70
22
Actual mains reactive power [kvar] 0% capacitive reactive power (negative) e.g. -0100 kvar
100% inductive reactive power (positive) e.g. +0100 kvar
The designation 0 % stands for either 4 mA or 0 mA; the designation 100 % stands for 20 mA. The values may
also be assigned with prefixes (see relay manager function 1).
