Manual 37128A GCP-20 Series - Genset Control
Page 48/190 © Woodward
Power Circuit Breaker Logic
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
NOTE
For the description of the switch logics please refer to the chapter Breaker Logic on page 98.
Parallel Switch Logic [GCP-21/22]
NOTE
This switch logic must be selected for the following operating modes: isolated operation, isolated op-
eration in parallel with other gensets and mains parallel operation.
In the event of a motor
request
the GCB is synchronized and closed
the required generator active load is adjusted
Following the with-
drawal of the motor
request
the generator power is reduced
the GCB is opened
the genset is shut down after the coasting (cool down time)
[GCP-22]
The mains power cir-
cuit breaker is syn-
chronized and closed if
terminal 53 "Release MCB" is energized
GCB closed
NOTE
On bucking the unit (no F3 alarm), power reduction is carried out before opening the generator power
circuit breaker.
Interchange Switch Logic [GCP-22]
Interchange synchronization is activated via the "INTERCHANGE" screen input.
In the event of a motor
request, a switch is
made from mains to
generator supply. In
order to achieve this
the GCB is synchronized and closed
the mains reference power "zero" is correspondingly adjusted
the MCB is opened
After the motor request
has been reset, a switch
is made from generator
to mains supply. In or-
der to achieve this
the MCB is synchronized and closed
the generator power "zero" is correspondingly adjusted (generator unloading)
the GCB is opened
