Manual 37128A GCP-20 Series - Genset Control
Page 176/190 © Woodward
Option
Parameter
1. Line Text 2. Line
Adjustment range Standard setting Customer settings
Code
level
C
ONTROLLER CONFIGURATION
Configure Contr.
YES/NO YES Y N Y N 2
Power controller P set1
C/I/E 0 to 3000 kW C 50 kW 1
Power controller P set2
C/I/E 0 to 6,900 kW C 80 kW 1
Load test via
Pset1 / Pset2 / Extern Pset1 P1 P2
E
P1 P2
E
1
QF
Initial state Freqency
0 to 100 % 50 % 2
..
Actuating signal Freq. min
0 to 100 % 0 % 2
QF
Actuating signal Freq. max
0 to 100 % 100 % 2
Freq. controller
ON/OFF ON on off on off 2
f-contr. active at:
0.0 to 70.0 Hz 30.0 Hz 2
Delay time for f-contr.
0 to 999 s 3 s 2
Freq. controller ramp
1 to 50 Hz/s 10 Hz/s 2
Freq. controller dead band
0.02 to 1.00 Hz 0.03 Hz 2
Freq. controller Time pulse>
10 to 250 ms 80 ms 2
Freq. controller Gain Kp
0.1 to 99.9 20.0 2
QF
Freq. controller Gain Kpr
1 to 240 10 2
..
Freq. controller Reset time
0.0 to 60.0 s 2.0 s 2
QF
Freq. controller Deriv.time
0.00 to 6.00 s 0.00 s 2
QU
Initial state Voltage
0 to 100 % 50 % 2
..
Actuating signal Volt. min
0 to 100 % 0 % 2
QU
Actuating signal Volt. max
0 to 100 % 100 % 2
Volt. controller
ON/OFF ON on off on off 2
V-contr. active at:
50 to 400 V 75/300 V 2
Delay time for V-contr.
0 to 999 s 3 s 2
Volt. controller dead band
0.1 to 15.0
0.5 to 60.0 V
3.5 V 2
Volt. controller Time pulse>
20 to 250 ms 80 ms 2
Volt. controller Gain Kp
0.1 to 99.9 20.0 2
QU
Volt. controller Gain Kpr
1 to 240 10.0 2
..
Volt. controller Reset time
0.0 to 60.0 s 2.0 s 2
QU
Volt. controller Deriv.time
0.00 to 6.0 s 0.0 s 2
Pow.fact. contr.
ON/OFF OFF on off on off 2
Pow.fact. contr. Setpoint
i0.70 to 1.00 to c0.70 1.00 1
Pow.fact. contr. Dead band
0.5 to 25.0 % 0.5 % 2
Pow.fact. contr. Gain Kp
0.1 to 99.9 20.0 2
QU
Pow.fact. contr. Gain Kpr
1 to 240 10 2
..
Pow.fact. contr. Reset time
0.2 to 60.0 s 2.0 s 2
QU
Pow.fact. contr. Deriv.time
0.0 to 6.0 s 0.0 s 2
Power controller
ON/OFF ON on off on off 2
Power controller ramp
0 to 100 %/s 10 %/s 2
Power cotroller ramp
0 to 100 kW/s 10 kW/s 2
Power limit P max.
10 to 120 % 100 % 2
Power limit P min.
0 to 50 % 0 % 2
X
Setpoint external
ON/OFF ON on off on off 2
..
Analog input
0 to 20/4 to 20 mA 4 to 20 mA 2
..
ext. setpoint 0mA
0 to 9,999 kW F0 kW 2
X
ext. setpoint 4mA
0 to 9,999 kW F200 kW 2
Power controller dead band
0.1 to 25.0 % 0.5 % 2
Power controller Gain Kp
0.1 to 99.9 20.0 2
P-contr. dead band ratio
1.0 to 9.9 2.0 2
QF
Power controller Gain Kpr
1 to 240 10 2
..
Power controller Reset time
0.2 to 60.0 s 2.0 s 2
QF
Power controller Deriv.time
0.0 to 6.0 s 0.0 s 2
Warm up load setpoint
5 to 110 % 15 % 2
Warm up load time
0 to 600 s 0 s 2
Active power Load-share
ON/OFF ON on off on off 2
Loadshare factor active pow.
10 to 99 % 50 % 2
Reactive power Load share
ON/OFF OFF on off on off 2
Loadshare factor react. pow.
10 to 99% 50 % 2
