Change breaker logic via terminal 64
Parameter 198
Open transition
by Term64 ON
Open transition via terminal 64 ON/OFF
OFF.............. This terminal is used as an alarm input.
ON................ This terminal is used as control input.
• High signal If this terminal utilizes a HIGH signal (energized),
the open transition breaker logic will be used.
• Low signal If this terminal utilizes a LOW signal (de-energized),
the breaker logic of
Parameter 104 will be used.
Enable 'Close GCB without engine delay' via terminal 67
Parameter 199
Close GCB asap
by Ter.67 ON
V1.0700 and above only
Close GCB before the del. engine monit. expires via terminal 67 ON/OFF
OFF.............. This terminal is used as an alarm input.
ON................ This terminal is used as control input.
• High signal If this terminal utilizes a HIGH signal (energized),
the GCB closes before the delayed engine monitoring
expires.
• Low signal If this terminal utilizes a LOW signal (de-energized),
the GCB closes after the delayed engine monitoring
has been expires.
Enable 'Emergency OFF' via terminal 68
Parameter 200
Emergency OFF
by Ter.68 OFF
V1.0700 and above only
Prevent an emergency power operation via terminal 68 ON/OFF
OFF.............. This terminal is used as an alarm input.
ON................ This terminal is used as control input.
• High signal If this terminal utilizes a HIGH signal (energized), an
emergency power operation is prevented or termi-
nated. The unit operates as if
Parameter 134 "Emer-
gency power" is disabled.
• Low signal If this terminal utilizes a LOW signal (de-energized),
the setting of
Parameter 134 "Emergency power" is
taken over.
