Manual 37128A GCP-20 Series - Genset Control
© Woodward Page 97/190
Set Point Specification via Interface X1 to X5 (Option SF)
Parameter 100
serial Control
com X1X5 ON
Option SF only
Control via interface COM X1 to X5 ON/OFF
ON................ Control via the interface is enabled if the direct configuration (Para-
meter 5) has been configured as "OFF", the control via Y1Y5 (
Para-
meter 81) has been configured to "ON", the operation mode is set to
AUTOMATIC and the discrete input "Automatic 2" (terminal 5) has
been enabled
. The engine can be started and stopped and the breakers
can be opened via a remote signal. The generator real power and the
generator power factor
ϕ set point value may also be transmitted.
OFF.............. The control via the X1X5 interface is disabled. The internally
generator real power set point value 2 (
Parameter 27) is selected with
the discrete input "Automatic 2" and the internal power factor (
Para-
meter 55) set point value is used. Interface monitoring is disabled.
Parameter 101
Remote acknow.
COM ON
Remote acknowledgment via interface ON/OFF
ON................ Alarm acknowledgement of alarms of the alarm classes F2/F3 via the
interface is enabled.
OFF.............. Alarm acknowledgement of alarms of the alarm classes F2/F3 via the
interface is disabled. Acknowledgment can be performed via the dis-
crete input "Acknowledgment" (terminal 6) or via the push button
"RESET".
Parameter 102
Supervision
COM ON
Remote monitoring of the interface ON/OFF
ON................ Monitoring of the interface is enabled. If control signals are not re-
ceived (ID 503) every 90 seconds, a warning alarm of class 1 is trig-
gered.
OFF.............. Monitoring of the interface is disabled.
