03/2003
4-135
8850/ 510DP
REP 10.9
Repairs and Adjustments
Figure 2 Removing the Screws Securing The Upper Sheet Feed Housing
3. (Figure 3): Remove the Upper Sheet Feed Housing.
Figure 3 Removing the Upper Sheet Feed Housing
1
Lower the Upper Sheet Feed Housing and pull to the
left to remove the tabs from the right side frame
