Xerox 8850 Service Manual

03/2003
6-45
8850/ 510DP
Product Specifications
General Procedures
Product Specifications
Physical Characteristics
(Figure 1): Printer front dimensions
Figure 1 Printer Front Dimensions
Minimum Space Requirements
(Figure 2): Printer footprint
Figure 2 Printer Footprint
Table 1 Physical Characteristics
Printer Dimensions
8850 510dp
Weight 575 lbs (261 kg) 575 lbs (261 kg)
Height 42.5 inches (1080 mm) 42.2 inches (1073 mm)
Width 23 inches (584 mm) 22.5 inches (572 mm)
Depth 57 inches (1450 mm) 59.3 inches (1505 mm)
Product Code CYK 3 drawer - MTT
2 drawer - MTR
1 drawer - MDH
42.5”
(1080 mm)
57” (1450 mm)
129” (3277 mm)
36”
(914 mm)
83” (2108 mm)
36”
(914 mm)
(610 mm)
36”
(914 mm)
24”
