03/2003
7-9
8850/ 510DP
BSD 1.1
Wiring Data
BSD 1.1 Main Power On (50 and 60 HZ)(2 of 2)
NOTE: 1: Refer to BSD 10.1 for the circuit of the Fuser Control PWB (A4).
NOTE: 2: Refer to the Controller Service Manual.
NOTE: 3: This Jumper is used by the manufacturer to test the Voltage Surge Protector. Do not
remove the connector.
NOTE: 4: The Varistor has been added to provide additional electrical noise suppression. If it
fails in a shorted condition, it will cause the Surge Voltage Protector to continually trip.
Figure 1 AC MODULE
A1A2P/J5 A1P/J8 A1P/J7 A1P/J3
To Next Page
