Xerox 8850 Service Manual

03/2003
7-11
8850/ 510DP
BSD 1.2
Wiring Data
Figure 1 Low Voltage Power Supplies
Figure 2 Main PWB(A3)
Table 1 INPUT POWER BLOCK
VOLTAGE TEST POINT GF
+3.3 VDC DC
COM+5
VDC+5VDC
(BULK)+12 VDC-
12 VDC+24 VDC
(FOR)+24 VDC
(BULK)
MAIN PWB (A3) J618 - 1
MAIN PWB (A3) J618 - 3
MAIN PWB (A3) J618 - 4
MAIN PWB (A3) J619 - 1
MAIN PWB (A3) J618 - 10
MAIN PWB (A3) J618 - 12
MAIN PWB (A3) J617 - 1
MAIN PWB (A3) J614 - 2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
24 VDC POWER
SUPPLY (A5PS2)
LVPS (A5PS1)
A5J614A5J618A5J617 A5J619
