03/2003
7-15
8850/ 510DP
BSD 1.3
Wiring Data
1.3 Interlock Monitoring (4 OF 4)
Figure 3 Top Cover Interlock
Figure 4 Cutter Drawer Interlock
TOP COVER INTER-
LOCK
CUTTER DRAWER
INTERLOCK
