Getting Started
Xerox
®
AltaLink
®
C80XX Series Multifunction Printer 33
User Guide
Business Ready Finisher with Optional Booklet Maker
1. Horizontal Transport Unit
2. Finisher Front Cover
3. Right Top Tray
4. Right Middle Tray
5. Staple Cartridge
6. Booklet Maker Tray
7. Booklet Staple Unit
8. Booklet Maker Unit
Business Ready Finisher with Optional C/Z Folder
1. Folder Front Cover
2. Folder Bin Release Button
3. Folder Bin
5
6
78
2 3
1
4
1 2 3
