ColorQube 8570/8870 Service Manual
PS NVRAM Reset
Revised, 3rd Revision - Xerox Internal Use Only
Fault Messages and Codes
PS NVRAM Reset
Many of the troubleshooting procedures in this section include an PS NVRAM reset as a pro-
cedural step. Following an NVRAM reset, the printer is unable to communicate on the network
and has lost several parameters specific to the customer’s configuration. If possible, print a
Configuration page to capture networking parameters. and discuss the customer’s configura
-
tion to document these settings before resetting NVRAM.
Table 1 lists the parameters reset by NVRAM Reset. Required parameters (Yes) must be con-
figured to restore default printer operation on the network.
Table 1 Parameters Reset with Service Diagnostics PS NVRAM Reset Command
Menu Parameter Default Required Comment
TCP/IPv4 Setup IPv4 On Yes
DHCP/BOOTP On Yes
AutoIP On Yes
IPv4 Address 0.0.0.0 Yes Set automati-
cally if DHCP/
BOOTP is
enabled
IPv4 Network Mask 0.0.0.0 Yes Automatically
calculated
based on IP
Address
IPv4 Gateway 0.0.0.0 Yes Automatically
set per RIP.
TCP/IPV6 Setup IPv6 Disabled Yes
Auto Assign On Yes Applicable
when IPv6 is
enabled.
Manual Address Off Yes Appears when
IPv6 is enabled.
Network Ser-
vices
Port 9100 On Yes
LPR On Yes
IPP On Yes
FTP On Yes
TFTP On Yes
WSD On Yes
SLP Off Yes
SSDP Off Yes
CentreWare IS On Yes
IPSec Off Yes
Network Setup Ethernet Speed Auto Yes
EtherTalk On Yes
USB Setup USB Port On Yes
Wait Timeout 30 secs Yes
Page Description Language AutoSelect Yes
Control Panel
Setup
Language English No
Control Panel Brightness 8 No
Control Panel Contrast 5 No
Accessible Control panel Off No
Menu Timeout 30 secs No
File Security Overwrite Removals Off No
Daily Removal Off No
Age-based Removal Off No
Paper Handling
Setup
Paper Source Auto
Select
No
2-Sided Printing Off No
Load Paper Timeout 3 mins No
Letter/A4 Substitution On No
Custom Units Inches No
Cleaning Page Source Highest No
Printer Controls Startup Page On No
Low Ink Warning Level 1000 No
Date and Time NA No Set by on-board
RTC.
Warm-up Mode Intelligent
Ready
No
Metric Defaults Off No
Fast Resume Off No
Paper Tray
Setup
Tray 1 Paper - Media Size Guide Size No
Tray 1 Paper - Media Type Plain No
Tray 2 Paper Type Plain No
Tray 3 Paper - (if installed) Plain No
Tray 4 Paper - (if installed) Plain No
Tray 5 Paper - (if installed) Plain No
Tray 1 Mode Dynamic No
Tray 1 Prompt 30 secs No
Tray 2 Mode Dynamic No Dependent on
number of
installed trays.
Tray 2-3 Mode Dynamic No Dependent on
number of
installed trays.
Table 1 Parameters Reset with Service Diagnostics PS NVRAM Reset Command
Menu Parameter Default Required Comment
