October 2012
xvii
ColorQube 8570/8870 Service Manual
Consumables, Printer Specifications
Introduction
Xerox Internal Use Only - Revised, 3rd Revision
ColorQube 8870 Ink SKU
Figure 4 Ink Stick Keys and SKU Flags Example - 8870
Printer Specifications
Print Engine Specifications
Memory Specifications
Table 3 Ink SKU Definitions - 8870
Location E F G H K 8870
North America (NA) E F G H x
Xerox Europe (XE) E F H x
Developing Markets Organization
(DMO)
E F G x
Metered E F G K x
NOTE: ColorQube 8870 Metered ink stick shown in Figure 4.
Table 1 Functional Specifications
Characteristic Specifications
Printing Process Four-color (CMYK) solid ink Printhead architecture.
Image System Transfix transfer from oil coated Drum.
Color Medium Cyan, Magenta, Yellow, and Black Ink Sticks, each shape-coded. the
printer uses the subtractive color system to produce the colors Red,
Green, and Blue.
Color Management • Automatic, Black & White
• Office: sRGB, sRGB Scientific, LCD Display, Vivid Color, None
• Press: Commercial, Euroscale, SWOP
Resolution • Fast Color: 225 x 400 dpi
• Standard: 300 x 450 dpi
• Enhanced: 525 x 450 dpi
• Photo: 525 x 2400 dpi
Warm-Up Time • From Cold Start: Less than 10 minutes
• From ENERGY STAR Mode: 2.5 minutes
Printer Life 5 year/ 225,000 pages
Recommended AMPV 4,000 prints/month
Operating System • Windows 2000/ 2003 Server/ XP/ Vista
• Macintosh: OS 10.3 or higher
•Linux
* Assumes a 30 day month of printing.
Table 2 Memory Specifications
Characteristic Specifications
Minimum RAM 512 MB
Maximum RAM 2 GB
Supported RAM Supports up to 2 GB of 512 MB or 1 GB DDR2 SDRAM using 2 slots.
