Xerox COLORQUBE 8870 Service Manual

October 2012
5-10
ColorQube 8570/8870 Service Manual
Xerox Supplies and Accessories
Revised, 3rd Revision - Xerox Internal Use Only
Parts List
Xerox Supplies and Accessories
Table 1 Consumables and Routine Maintenance Items
Description Part Number
Xerox ColorQube Ink (C), ColorQube 8570 (2 Sticks), North America 108R00926
Xerox ColorQube Ink (M), ColorQube 8570 (2 Sticks), North America 108R00927
Xerox ColorQube Ink (Y), ColorQube 8570 (2 Sticks), North America 108R00928
Xerox ColorQube Ink (K), ColorQube 8570 (2 Sticks), North America 108R00929
Xerox ColorQube Ink (K), ColorQube 8570 (4 Sticks), North America 108R00930
Xerox ColorQube Ink (C), ColorQube 8570 (2 Sticks), Europe 108R00931
Xerox ColorQube Ink (M), ColorQube 8570 (2 Sticks), Europe 108R00932
Xerox ColorQube Ink (Y), ColorQube 8570 (2 Sticks), Europe 108R00933
Xerox ColorQube Ink (K), ColorQube 8570 (2 Sticks), Europe 108R00934
Xerox ColorQube Ink (K), ColorQube 8570 (4 Sticks), Europe 108R00935
Xerox ColorQube Ink (C), ColorQube 8570 (2 Sticks), DMO 108R00936
Xerox ColorQube Ink (M), ColorQube 8570 (2 Sticks), DMO 108R00937
Xerox ColorQube Ink (Y), ColorQube 8570 (2 Sticks), DMO 108R00938
Xerox ColorQube Ink (K), ColorQube 8570 (2 Sticks), DMO 108R00939
Xerox ColorQube Ink (K), ColorQube 8570 (4 Sticks), DMO 108R00940
Xerox ColorQube Ink (C), ColorQube 8570 (2 Sticks), Asia Pacific 108R00941
Xerox ColorQube Ink (M), ColorQube 8570 (2 Sticks), Asia Pacific 108R00942
Xerox ColorQube Ink (Y), ColorQube 8570 (2 Sticks), Asia Pacific 108R00943
Xerox ColorQube Ink (K), ColorQube 8570 (2 Sticks), Asia Pacific 108R00944
Xerox ColorQube Ink (K), ColorQube 8570 (4 Sticks), Asia Pacific 108R00945
Xerox ColorQube Ink Metered (C), ColorQube 8570 (4 Sticks), Metered 108R00946
Xerox ColorQube Ink Metered (M), ColorQube 8570 (4 Sticks), Metered 108R00947
Xerox ColorQube Ink Metered (Y), ColorQube 8570 (4 Sticks), Metered 108R00948
Xerox ColorQube Ink Metered (K), ColorQube 8570 (4 Sticks), Metered 108R00949
Xerox ColorQube Ink (C), ColorQube 8870 (6 Sticks), North America 108R00950
Xerox ColorQube Ink (M), ColorQube 8870 (6 Sticks), North America 108R00951
Xerox ColorQube Ink (Y), ColorQube 8870 (6 Sticks), North America 108R00952
Xerox ColorQube Ink (K), ColorQube 8870 (6 Sticks), North America 108R00953
Xerox ColorQube Ink (C), ColorQube 8870 (6 Sticks), Europe 108R00954
Xerox ColorQube Ink (M), ColorQube 8870 (6 Sticks), Europe 108R00955
Xerox ColorQube Ink (Y), ColorQube 8870 (6 Sticks), Europe 108R00956
Xerox ColorQube Ink (K), ColorQube 8870 (6 Sticks), Europe 108R00957
Xerox ColorQube Ink (C), ColorQube 8870 (6 Sticks), DMO 108R00958
Xerox ColorQube Ink (M), ColorQube 8870 (6 Sticks), DMO 108R00959
Xerox ColorQube Ink (Y), ColorQube 8870 (6 Sticks), DMO 108R00960
Xerox ColorQube Ink (K), ColorQube 8870 (6 Sticks), DMO 108R00961
Xerox ColorQube Ink Metered (C), ColorQube 8870 (6 Sticks), Metered 108R00962
Xerox ColorQube Ink Metered (M), ColorQube 8870 (6 Sticks), Metered 108R00963
Xerox ColorQube Ink Metered (Y), ColorQube 8870 (6 Sticks), Metered 108R00964
Xerox ColorQube Ink Metered (K), ColorQube 8870 (6 Sticks), Metered 108R00965
Maintenance Kit, Standard Capacity, ColorQube 8570/8870 109R00784
Maintenance Kit, Extended Capacity, ColorQube 8570/8870 109R00783
Waste Tray 109R00754
Rainbow Pack 058K00250
Table 2 Options
Description Part Number
525-Sheet Feeder 059K76570
Printer Cart 137E11900
Wireless Network Adapter with NA power converter 110V 097S03740
Wireless Network Adapter with Euro power converter 220V 097S03741
Wireless Network Adapter with UK power converter 220V 097S03742
Table 3 Power Cords
Description Part Number
Power Cord, North America (NEMA 5-15), 115V, 13A 117E35170
Power Cord, Euro, 230V 117E29500
Power Cord, UK, 240V 117E29510
Power Cord, Australia, 230V 117E29490
Power Cord, Switzerland, 230V 117E35050
Power Cord, Denmark, 230V 117E29460
Power Cord, China, 220V 117E35030
Power Cord, Argentina, 220V 117E35040
Power Cord, Italy, 230V 117E29450
Power Cord, Israel, 230V 117E29480
Power Cord, India/ South Africa, 230V 117E29470
Table 4 Kits and Other Items
Description Part Number
Mechanical Hardware Kit 604K42210
Repackaging Kit 695K22810
Grease, Nye Rheolube 368F 070E00890
Tool, Screwdriver, Torque, Adjust 003082700
Bit, Screwdriver, 0.25 Hexdrive, T20 003086600
CA ASSY,SP; Discrete, Serial Adapter; Crimp 5,26 AWG,(1 X 5, JACK TIP)
X (DSUB, Female, STR, 25 POS, AMP 147913-7); High Reliability
600T80374
Cable, Serial, DB9F-DB25M,
PC Null-Modem Type; Belkin #F2L044-10
600T80375
Printhead ZIF Connector Unlock/Lock Tool 650K32910
Table 1 Consumables and Routine Maintenance Items
Description Part Number

Xerox COLORQUBE 8870 Specifications

General

Wi-Fi	-
Network ready	Yes
Security algorithms	HTTPS, SSL/TLS
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum duty cycle	120000 pages per month
Recommended duty cycle	15000 pages per month
Page description languages	PCL 5c, PostScript 3
Maximum internal memory	2048 MB
Sound power level (standby)	24 dB
Display	LCD
Certification	EMC Directive 2004/108/EC, FCC Part 15, Class A, Low Voltage Directive 2006/95/EC, RoHS Directive 2002/95/EC
Total input capacity	625 sheets
Total output capacity	350 sheets
Maximum input capacity	2200 sheets
Envelopes sizes	C5, DL
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 220
Paper tray media types	Bond paper, Card stock, Coated paper, Envelopes, Glossy paper, Labels, Photo paper, Plain paper, Recycled paper, Transparencies
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Bond paper, Business cards, Envelopes, Greeting cards, Heavyweight paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	107 W
Power consumption (printing)	252 W
Power consumption (PowerSave)	47 W
Package weight	35811 g
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Depth (imperial)	20.5 \
Width (imperial)	16 \
Height (imperial)	14.5 \
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.1x
Minimum storage drive space	160 GB
Compatible operating systems	HP UX 11, HP UX 11i, Linux, Mac OS 10.5+, Solaris 10, Solaris 9, Windows 2003 Server, Windows 2008 Server, Windows 7, Windows Vista, Windows XP, Windows XP Pro

Weight and Dimensions

Depth	521 mm
Width	406 mm
Height	368 mm
Dimensions (WxDxH)	406 x 521 x 368 mm
