Red Solid Fills, Blue Solid Fills
Revised, 3rd Revision - Xerox Internal Use Only
Image Quality
Red Solid Fills
This test prints Red solid fills in two modes.
• 1x: Prints 1 page of Red solid fills single-sided.
• 10x: Prints 10 pages of Red solid fills single-sided.
Figure 1 Red Solid Fills
Green Solid Fills
This test prints Green solid fills in two modes.
• 1x: Prints 1 page of Green solid fills single-sided.
• 10x: Prints 10 pages of Green solid fills single-sided.
Figure 1 Green Solid Fill
Blue Solid Fills
This test prints Blue solid fills in two modes.
• 1x: Prints 1 page of Blue solid fills single-sided.
• 10x: Prints 10 pages of Blue solid fills single-sided.
Figure 1 Blue Solid Fills
