Xerox PHASER 6130 Service Manual

3-10 Phaser 6130 Color Laser Printer Service Manual
Error Messages and Codes
116-390 NV RAM Error
Restart Printer
Error 116-390
Restart Printer
<ESS NVRAM1 SIZE And ID
Check Fail>
The error is detected by
consistency check between
NVRAM size required by the
system and its actual size, and by
consistency check of ID recorded
when turning ON the power.
page 3-24
Toner Cartridge Errors
Insert
Yellow Cartridge
<IOT Y CRU Detached>
Yellow Cartridge detached is
detected.
page 3-27
Insert
Magenta Cartridge
<IOT M CRU Detached>
Magenta Cartridge detached is
detected.
page 3-27
Insert
Cyan Cartridge
<IOT C CRU Detached>
Cyan Cartridge detached is
detected.
page 3-27
Insert
Black Cartridge
<IOT K CRU Detached>
Black Cartridge detached is
detected.
page 3-27
Non-Xerox Toner
Invalid Yellow
<IOT CRUM ID Error>
CRUM ID error of Yellow
Cartridge is detected.
page 3-27
Non-Xerox Toner
Invalid Magenta
<IOT CRUM ID Error>
CRUM ID error of Magenta
Cartridge is detected.
page 3-27
Non-Xerox Toner
Invalid Cyan
<IOT CRUM ID Error>
CRUM ID error of Cyan Cartridge
is detected.
page 3-27
Non-Xerox Toner
Invalid Black
<IOT CRUM ID Error>
CRUM ID error of Black Cartridge
is detected.
page 3-27
%s Replace Yellow
and
Replace
Yellow Cartridge
<IOT Y CRU Life Over>
Yellow Cartridge has reached end-
of-life.
page 3-27
%s Replace Magenta
and
Replace
Magenta Cartridge
<IOT M CRU Life Over>
Magenta Cartridge has reached
end-of-life.
page 3-27
%s Replace Cyan
and
Replace
Cyan Cartridge
<IOT C CRU Life Over>
Cyan Cartridge has reached end-
of-life.
page 3-27
Error Message and Chain Link Code Display (continued)
Chain Link
Code
Control Panel
Message Error Contents
Go to
Page
Scrol
l

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
