Xerox PHASER 6130 Service Manual

3-14 Phaser 6130 Color Laser Printer Service Manual
Error Messages and Codes
018-316 MPC Error
Restart Printer
Error 018-316
Restart Printer
<MPC Internal Loopback Error>
The error is detected by Loopback
test.
page 3-50
018-317 MPC Error
Restart Printer
Error 018-317
Restart Printer
<MPC Fatal Error>
The error is detected by MPC
check.
page 3-50
116-333 MPC error
Restart Printer
Error 116-333
Restart Printer
<PCI Option#0 Fail>
Detection error of PCI option 0.
page 3-50
Transfer Unit Errors
092-310 CTD Sensor Error
Restart Printer
Error 092-310
Restart Printer
092-310
Code: XXXX
<IOT CTD (ADC) Sensor Error>
Shows detail of error code when
pressing three keys Down arrow,
Up arrow, and OK.
092-310
Code:
0801:fail 1/
0802: Fail 2
page 3-51
094-330 DTB Life Over
Restart Printer
Error 094-330
Restart Printer
<IOT DTB Life Over>
Imaging Unit reached the
replacement time.
page 3-52
Check Unit
CTD Sensor
<IOT CTD (ADC) Sensor
Contamination>
Contamination of the ADC Sensor
is detected.
page 3-51
CTD Sensor <IOT CTD (ADC) Sensor
Contamination>
Contamination of the ADC Sensor
is detected.
page 3-51
Insert
Imaging Unit
<IOT PHD Detached>
Imaging Unit detached is
detected.
page 3-53
Low Density
Yellow Cartridge
<IOT Y Toner Low Density>
Detects low density of yellow.
page 3-54
Error Message and Chain Link Code Display (continued)
Chain Link
Code
Control Panel
Message Error Contents
Go to
Page
Scrol
l
Scrol
l
Scrol
l
Scrol
l
Scrol
l
Scrol
l

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
