Xerox PHASER 6130 Service Manual

3-16 Phaser 6130 Color Laser Printer Service Manual
Error Messages and Codes
Fuser Errors
010-317 Insert Fuser
010-317
Insert Fuser
Restart Printer
<IOT Fuser Detached>
Detached Fuser is detected.
page 3-62
010-351 Replace Fuser
010-351
Replace Fuser
Restart Printer
<IOT Fuser Life Over>
Fuser has reached replacement
time.
page 3-63
010-397 Fuser Error
Restart Printer
Error 010-397
Restart Printer
010-397
Code: XX
<IOT Fuser Failure>
Fuser Failure is detected.
Shows detail of error code when
pressing three keys “Down
arrow”, “Upper arrow”, and “OK”
010-397
Code: XX
01: NC circuit fail/
02: NC Detect disconnection/
03: NC Detect fail/
04: NC Comp disconnection/
05: NC Comp fail/
06: NC Temp Over/
07: STS Temp Over/
08: NC Comp Table Fail/
09: NC Overheat/
0A: STS disconnection/
0B: STS Overheat/
0C: STS Lowtemp/
0D: NC Lowtemp/
0E: Cool Timeover/
0F: Fuser Ready Time over ERR1/
10: NC Warm up Time over ERR2/
11: Fuser Ready Time over ERR2/
12: Relay Off STS H/
13: Relay Off NC H/
14: Relay Other/
15: Fuser Machine Code ERR/
16: Fuser Ready Time over ERR3
page 3-64
Fuser Life
Replace Soon
<IOT Fuser Life Pre Warning>
Fuser is going to reach
replacement time.
page 3-63
Error Message and Chain Link Code Display (continued)
Chain Link
Code
Control Panel
Message Error Contents
Go to
Page
Scrol
l
Scrol
l
Scrol
l
Scrol
l

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
