Xerox PHASER 6130 Service Manual

3-18 Phaser 6130 Color Laser Printer Service Manual
Error Messages and Codes
MCU Errors
024-340 MCU Firmware Err
Restart Printer
Error 024-340
Restart Printer
024-340
Code: XX
<IOT Firmware Error>
Firmware error occurs.
Shows detail of error code when
pressing three keys “Down
arrow”, “Up arrow”, and “OK”.
024-340
Code: XX
01: Task Over/
02: Time Over/
03: NV Write Retry/
04: NV Write Queue Over/
05: LEISUS Send Over/
06: CRUM Data/
07: Pursuit Comp/
08: Pursuit SUM/
09: Fuser NV/
0A: Dispense/
0B: FSR SBY Mode/
0C: Media ERR2/
0D: Hanpa/
0E: FSR SBY Mode/
0F: FSR Print Mode/
10: Continuous Heater/
11: PPM Group ERR/
12: CMODE ERR/
13: Send CMD ERR
page 3-74
041-340 MCU NVRAM Error
Restart Printer
Error 041-340
Restart Printer
ADDR: XXXX
Data: XX
<IOT NVRAM Error>
IOT NVM Error occurs.
Shows detail of error code and
address when pressing three keys
“Down arrow”, “Upper arrow”,
and “OK”.
ADDR: XXXX
Data: XX
1000 to 17FF: MCU PWBA/
3000 to 30FF: Transfer Belt/
3100 to 31FF: Yellow Toner
Cartridge/
3200 to 32FF: Magenta Toner
Cartridge/
3300 to 33FF: Cyan Toner
Cartridge/
3400 to 34FF: Black Toner
Cartridge
page 3-75
Error Message and Chain Link Code Display (continued)
Chain Link
Code
Control Panel
Message Error Contents
Go to
Page
Scrol
l
Scrol
l
Scrol
l
Scrol
l

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
