3-36 Phaser 6130 Color Laser Printer Service Manual
Error Messages and Codes
12 Check the Regi Sensor (Photo Sensor)
for operation
Check the voltage across P23-5 <=>
ground on the MCU Board.
Does the voltage change, when the
actuator of the Regi Sensor (Photo
Sensor) is operated?
Replace the
MCU Board
(page 8-59).
Replace the Regi
Sensor (Photo
Sensor).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
