Xerox PHASER 6130 Service Manual

4-10 Phaser 6130 Color Laser Printer Service Manual
General Troubleshooting
PANEL Test PANEL Test
■ Start
Checks input and output of the Control
Panel buttons. When buttons are
pressed as shown, the test displays the
corresponding contents on the LED.
Button LCD
Note: To exit the Panel Test, press the Up and Down buttons
simultaneously.
Up Displays Up on the LCD.
Down Displays Down on the LCD.
Left Displays Left on the LCD.
Right Displays Right on the LCD.
OK Displays Set on the LCD.
Menu Displays Menu on the LCD.
Cancel Displays Cancel Job on the LCD.
Wake Up Displays Power Saver on the LCD.
Engine Test Engine Test
■ Start
■ Check OK
Performs communication test with the
Engine Controller. Then it reads the
status register of the engine to check
whether commands can be exchanged
with the engine.
Engine Diag Performs function checks on components to determine whether
they operate normally or not.
Note: During Engine Diag test, other Service Diagnostics functions
cannot be performed simultaneously.
Sensor Test Tests the sensors of the printer. The
“L” and “H” values increment with each
actuation of the sensor under test.
Exit Sensor Exit Sensor
■ OFF
■ L - 0
■ H - 0
Tests the Exit Sensor.
Regi Sensor Regi Sensor
■ OFF
■ L - 0
■ H - 0
Tests the Registration Sensor.
Cover Open
Sensor
Cover Open Sensor
■ OFF
■ L - 0
■ H - 0
Tests the Front Cover Interlock Switch.
Side Switch Side Switch
■ OFF
■ L - 0
■ H - 0
Tests the Side Door Open switch.
Test Control Panel Display Test Description

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
