Xerox PHASER 6130 Service Manual

4-12 Phaser 6130 Color Laser Printer Service Manual
General Troubleshooting
Drum Erase
Lamp K
Drum Erase Lamp K Tests the black Erase Lamp.
Drum Erase
Lamp YMC
Drum Erase Lamp YMC Tests the yellow, magenta, and cyan
Erase Lamps.
NVM Settings Edits, saves, loads, and prints NVRAM information.
Edit NVM Edit NVM
■ Ad0000=00000000*
■ Please wait
<Press the Left or Right
button to move the
cursor>
<Press the Up or Down
button to change the
value at the cursor>
<Press the Set button to
save the value in Engine
NVM>
<Press the Cancel button
to move one level up the
menu>
Displays the current NVRAM value.
Use this function to edit NVRAM
information.
Save NVM to
ESS
Save NVM
■ SaveNVM MCU -> ESS
OK?
■ Saved
■ Please wait
<Press the Set button to
save the value in the
Controller NVM>
<Press the Cancel button
to move one level up the
menu>
Saves the NVRAM information of the
Engine in the Controller. NVRAM
addresses to be saved are as follows:
1000-10FF, Total: 256Byte
Note: Information saved in the
Controller NVM can be initialized using
Clear All NVM.
Load NVM from
ESS
Load NVM
■ LoadNVM MCU -> ESS
OK?
■ Processing
■ Loaded
■ Please wait
<Press the Set button to
load the value saved in
the Controller NVM to the
Engine>
<Press the Cancel button
to move one level up the
menu>
Loads NVRAM information of the
Engine saved in the Controller into the
Engine.
1000-10FF / 1100-11FF / 1200-12FF
Note: Information saved in the
Controller NVM can be initialized using
Clear All NVM.
Test Control Panel Display Test Description

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
