4-16 Phaser 6130 Color Laser Printer Service Manual
General Troubleshooting
Clear All NVM Clear All NVM
■ OK?
■ Processing
■ Initialized
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
run the test>
Clears all NVRAM of the Controller.
Clear Job
History
Clear JobHistory
■ OK?
■ Processing
■ Initialized
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
run the test>
Deletes the job history data.
Note: Job History can also be
initialized by Clear All NVM.
Clear
Auditron PV
Not used in this printer.
Test Print Provides various test prints to be used for troubleshooting the
printer.
No Image IOT No Image IOT
■ Ready
■ Processing
Prints a blank page.
Pattern IOT Pattern IOT
■ Ready
■ Processing
Prints the printer built-in Test Pattern
600 DPI. This test checks the print
function of the printer.
Grid 2 ESS Grid 2 ESS
■ Ready
■ Processing
Prints the Controller built-in grid
pattern. This test checks the print
function of the printer.
Cyan 20% ESS Cyan 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
cyan on the whole page.
Magenta 20%
ESS
Magenta 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
magenta on the whole page.
Yellow 20%
ESS
Yellow 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
yellow on the whole page.
Black 20% ESS Black 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
black on the whole page.
CMY 20% ESS CMY 20% ESS
■ Ready
■ Processing
Prints 20% density paint pattern of
cyan, magenta, and black combined on
the whole page.
Test Control Panel Display Test Description
