4-18 Phaser 6130 Color Laser Printer Service Manual
General Troubleshooting
Fast Scan 2
KtoM
Fast Scan 2 KtoM
■ -1 *
■ :
■ 2 *
Sets the registration in the paper
feeding direction for Manual Feed and
Tray. Adjusts by one-quarter pixel per
unit.
Fast Scan 2
KtoY
Fast Scan 2 KtoY
■ -1 *
■ :
■ 2 *
Fast Scan 2
KtoC
Fast Scan 2 KtoC
■ -1 *
■ :
■ 2 *
Life Y Toner Life Y Toner
■ 0
Reads life counter of the yellow toner.
Life M Toner Life M Toner
■ 0
Reads life counter of the magenta
toner.
Life C Toner Life C Toner
■ 0
Reads life counter of the cyan toner.
Life K Toner Life K Toner
■ 0
Reads life counter of the black toner.
Life Fuser
Sheet
Life Fuser
■ 0
Reads sheet count of the Fuser.
Life Printer
Sheet
Life Printer
■ 0
Reads sheet count of the Printer.
Life DTB Waste Life DTB Waste
■ 0
Reads life counter of the Belt Waste
Count.
Life Y
Waste Toner
Life YWaste Toner
■ 0
Reads life counter of the yellow Waste
Toner.
Life M
Waste Toner
Life MWaste Toner
■ 0
Reads life counter of the magenta
Waste Toner.
Life C
Waste Toner
Life CWaste Toner
■ 0
Reads life counter of the cyan Waste
Toner.
Life K
Waste Toner
Life KWaste Toner
■ 0
Reads life counter of the black Waste
Toner.
Life IU Y Time Life IU Y Time
■ 0
Reads dispense time of the yellow
Developer.
Life IU M Time Life IU M Time
■ 0
Reads dispense time of the magenta
Developer.
Life IU C Time Life IU C Time
■ 0
Reads dispense time of the cyan
Developer.
Life IU K Time Life IU K Time
■ 0
Reads dispense time of the black
Developer.
Test Control Panel Display Test Description

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
