5-50 Phaser 6130 Color Laser Printer Service Manual
Print-Quality Troubleshooting
13 Reseat the connectors on the MCU
Board.
Is the image printed correctly?
Complete Go to step 14.
14 Reseat the connectors on the IP
Board.
Is the image printed correctly?
Complete Go to step 15.
15 Open and close the Front Cover to
reseat the Transfer Unit.
Is the image printed correctly?
Complete Go to step 16.
16 Replace the Imaging Unit (page 8-8).
Is the image printed correctly?
Complete Go to step 17.
17 Replace the IP Board (page 8-60).
Is the image printed correctly?
Complete Replace the
MCU Board
(page 8-59).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
