Xerox PHASER 6130 Service Manual

Phaser 6130 Color Laser Printer Service Manual 5-55
Print-Quality Troubleshooting
3 Open and close the Front Cover.
Does the Front Cover latch closed
properly?
Complete Replace any
defective parts,
then go to step
4.
4 Is the image printed correctly? Complete Go to step 5.
5 Reseat the Imaging Unit.
Is the image printed correctly?
Complete Go to step 6.
6 Reseat the Fuser.
Warning: Start the operation after the
Fuser has cooled down.
Is the image printed correctly?
Complete Go to step 7.
7 Open and close the Front Cover to
reseat the Transfer Unit.
Is the image printed correctly?
Complete Go to step 8.
8 Is the paper damaged when fed from
the Manual Feed Slot?
Go to step 9. Go to step 12.
9 Check the setting of the Manual Feed
Slot side guides and reset the side
guides if needed.
Is the image printed correctly?
Complete Go to step 10.
10 Inspect the paper path.
Is there any contamination on the
paper path?
Clean the paper
path (refer to
“Cleaning” on
page 7-2), then
go to step 11.
Go to step 12.
11 Is the image printed correctly? Complete Go to step 12.
12 Reseat the Paper Tray.
Is the image printed correctly?
Complete Go to step 13.
13 Reset the Paper Tray side guides.
Is the image printed correctly?
Complete Go to step 14.
14 Replace the paper in the Paper Tray
with new paper.
Is the image printed correctly?
Complete Go to step 15.
15 Inspect the paper path.
Is there any contamination on the
paper path?
Clean the paper
path (refer to
“Cleaning” on
page 7-2), then
go to step 16.
Go to step 17.
16 Is the image printed correctly? Complete Go to step 17.
17 Reseat the Separator Roller Assembly.
Is the image printed correctly?
Complete Go to step 18.
18 Replace the Separator Roller
Assembly (page 8-7).
Is the image printed correctly?
Complete Go to step 19.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
