Xerox PHASER 6130 Service Manual

6-4 Phaser 6130 Color Laser Printer Service Manual
Adjustments and Calibrations
Manual Color Registration Adjustment
Color registration can be adjusted manually by a user or automatically by the
printer. Color registration should be adjusted any time the printer is moved.
The color registration can be fine tuned by performing a manual adjustment.
N
o
t
e
An automatic color registration adjustment is performed every time a new
Print Cartridge is installed.
Horizontal Registration
Section 1 of the Color Registration Correction Chart displays a series of lines.
Some lines are straight, with both the colored and black segments aligned,
while other lines are jagged, with the colored segments offset to the right or
left. A value is listed next to each line. When the value is 0, the color
registration needs no adjustment.
To determine correction values for Horizontal Registration, choose the
straightest line. If the value listed next to the straight line is anything other than
0, follow the procedure below to enter values.
N
o
t
e
The densest colors of the grid can also be used to find the straightest
lines. The colors printed at the highest density are those next to the
straight lines.
To enter values:
1. From the Control Panel, press the Menu button.
2. Press the Up Arrow or Down Arrow button to find Admin Menu. Press
the OK button.
3. Press the Up Arrow or Down Arrow button to find Maintenance Mode.
Press the OK button.
4. Press the Up Arrow or Down Arrow button to find Adjust Color Regi.
Press the OK button.
5. Press the Up Arrow or Down Arrow button to find Enter Number. Press
the OK button.
6. Press the Up Arrow or Down Arrow button to find Fast Scan. Press the
OK button.
7. Use the Up Arrow or Down Arrow button to enter the values and the
Right Arrow button to move from Y to M to C.
8. Repeat step 2 to continue adjusting the color registration.
9. Press the OK button twice to print the Color Registration Correction Chart
with the new values. The color registration adjustment is complete when
the straightest Y, M, and C lines are next to the 0 line.
Note
If 0 is not displayed next to the straightest lines, determine the values
and adjust again.

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
