Phaser 6130 Color Laser Printer Service Manual 9-5
Parts List
Parts List 1.1 Covers
ID No. Name/Description
Part Number
1 Cover Top 848E20100
2 Tray Ext 050E24201
3 Cover Rear 848E20072
4 Cover Cst 848E20121
5 Cover Window Tnr (Toner Access Door) 848K10661
6 Cover Side R 848E20091
7 Cover Assy Front (with 8-17) 675K61041
8 Latch Front —
9 Plate Latch —
10 Spring Latch Out —
11 Button Latch —
12 Cover Front
13 Guide Belt —
14 Damper Front L —
15 Damper Front S —
16 Cover Harness —
17 Harness Assy A-OP (J220-P2900) 962K60030
18 Shaft Pivot —
19 Control Panel Assy 848K09303
20 Cover Side L 848E20081
21 — —
99 Kit Shaft Pivot (with 18 × 2pcs) 675K54050
