Phaser 6130 Color Laser Printer Service Manual 9-7
Parts List
Parts List 2.1 Paper Tray
ID No. Name/Description
Part Number
1 CASSETTE ASSY 250 (with 2-19) 050K61151
2 PLATE ASSY BOTTOM —
3 SPRING N/F L —
4 SPRING N/F R —
5 SEPARATOR ROLLER ASSEMBLY 019K09470
6 GUIDE SIDE L —
7 GEAR PINION —
8 GUIDE SIDE ASSY R —
9 COVER SSI —
10 GUIDE SIDE SSI L —
11 RACK GUIDE SIDE SSI L —
12 RACK GUIDE SIDE SSI R —
13 GUIDE SIDE SSI R —
14 LATCH BOTTOM L —
15 LATCH BOTTOM R —
16 SPRING LEVER —
17 TRAY ASSY EXTENSION —
18 HOUSING CST 250 —
19 HANDLE CST —
