Phaser 6130 Color Laser Printer Service Manual 9-9
Parts List
Parts List 3.1 Paper Feeder (1 of 2)
Item Parts name Part Number
1 CLUTCH ASSY DRV —
2 BEARING REGI —
3 FEEDER ASSY NV (with 4-13,16-18,PL3.2.1,PL8.2.7,PL9.1.6) 059K56390
4 CHASSIS FDR R —
5 FOOT —
6 PLATE EARTH PH —
7 STOPPER CST 003E73341
8 CHASSIS FDR L —
9 SOLENOID FEED MSI —
10 SPRING LEVER —
11 LEVER FEED —
12 SPRING FEED IN —
13 SPRING FEED OUT —
14 GEAR ASSY FEED (with 15,16) —
15 GEAR FEED OUT —
16 GEAR FEED IN —
17 BEARING —
18 HARN ASSY L SIDE (J23,J28-P231,J232,J233,J234,J281) 962K57541
98 KIT SOLENOID FEED (with 9-14) 675K54150
99 KIT CLUTCH ASSY DRV (with 1,2) 675K54230
To Next Page
