Phaser 6130 Color Laser Printer Service Manual 9-13
Parts List
Parts List 4.1 Xerographics
ID No. Name/Description Part Number
1
ROS ASSY (Laser Unit)
a
—
2 SPRING ROS —
3 HOLDER CRUM —
4 SPRING PHD —
5 LEVER PHD —
6 BLOCK STOPPER PHD D —
7 BLOCK STOPPER PHD AD —
8 LED ASSY ERASE 122K94040
9 SPRING TRACKING —
10 SPRING CF —
11 SPRING TR4 —
12 SPRING TR3 —
13 SPRING TR2 —
14 SPRING TR1 —
15 SPRING D4 —
16 SPRING D3 —
17 SPRING D2 —
18 SPRING D1 —
19 PWBA HVPS 105K22661
20 FRAME HVPS 801E01503
21 PHD ASSY (Imaging Unit) 675K69240
22 HARN ASSY ROS RE (J40-J411) —
23 HARN ASSY ROS VIDEO (J41-J412) —
97 KIT BLOCK PHD RIGHT (with 4,5,7 × 2pcs) 675K54241
98 KIT BLOCK PHD LEFT (with 4,5,6 × 2pcs) 675K54251
99 KIT ROS (with 1,2 × 2pcs) (Laser Unit kit) 604K43050
a. Use PL4.1.99, Laser Unit kit, when ordering the Laser Unit.
