Xerox PHASER 6130 Service Manual

Phaser 6130 Color Laser Printer Service Manual 9-15
Parts List
Parts List 5.1 Dispenser
ID No. Name/Description Part Number
1 DISPENSER ASSY (with 2,9-11,14-16,25-27) 094K92290
2 FRAME ASSY MOT (with 3-8) —
3 MOTOR ASSY DISP —
4 CONDUCTOR MOTOR —
5 FRAME MOTOR —
6 GEAR IDLER —
7 GEAR IDLER AUG —
8 GEAR IDLER AGI —
9 SWITCH (R Side Door) 110E10200
10 HOUSING ASSY AUGER —
11 FRAME ASSY DISP (with 12,13) —
12 FRAME DISP —
13 SEAL DISP AUG —
14 CONNECTOR CRUM —
15 SPRING DISP —
16 JOINT ASSY DISP —
17 HOLDER TCRU K 604K44920
18 HOLDER TCRU C 604K44930
19 HOLDER TCRU M 604K44940
20 HOLDER TCRU Y 604K44950
21B TONER CARTRIDGE US/EU 2.5K (K) 675K59231
21C TONER CARTRIDGE DMO 2.5K (K) 675K59311
22B TONER CARTRIDGE US/EU 2K (C) 675K59241
22C TONER CARTRIDGE DMO 2K (C) 675K59321
23B TONER CARTRIDGE US/EU 2K (M) 675K59251
23C TONER CARTRIDGE DMO 2K (M) 675K59331
24B TONER CARTRIDGE US/EU 2K (Y) 675K59261
24C TONER CARTRIDGE DMO 2K (Y) 675K59341
25 HARN ASSY TNR MOT (J18,J19-J181,J182,J191,J192) —
26 HARN ASSY TONER CRUM (J31-J311,J312,J313,J314) —
27 HARN ASSY SIDE SW (J29-J291) —
28 HARN ASSY TEST RL (J504-P5041) —

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
