Phaser 6130 Color Laser Printer Service Manual 10-5
Plug/Jack and Wiring Diagrams
483 3 G-140 Connects GFI Breaker and Power Switch Harness
Assy
484 3 G-141 Connects GFI Breaker and GFI Ground Harness Assy
501 3 D-136 Connects LVPS Board and LVPS Harness Assy
502 3 C-136 Connects LVPS Board and 24V Harness Assy
503 3 C-136 Connects LVPS Board and FAN
504 3 D-136 Connects LVPS Board and RL Test Harness Assy
2811 1 D-107 Connects ADC Sensor and ADC SNR2 Harness Assy
(Transfer Belt)
5041 1 I-107 No Connection (Used in production process only)
2200/
2900
1 H-111 Connects A-OP Harness Assy and B Harness Assy
Print Engine Plug/Jack Designators (continued)
P/J Map Coordinates Remarks
