10-32 Phaser 6130 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
Signal Line Name Description
TEST PRINT Controls signal for the Test Print mode.
DEEP SLEEP Controls signal for the Deep Sleep mode.
STS Status signal transmitted from the MCU Board to the
Image Processor Board.
CMD Commands signal transmitted from the Image
Processor Board to the MCU Board.
CREADY Signal for indicating whether or not the printer is ready
for receiving command signal.
SREADY
VSYNC K Signal for indicating registration position of each of
images Y, M, C, and K.
VSYNC C
VSYNC M
VSYNC Y
HSYNC Signal for data.
DATA K Video data of four colors.
DATA C
DATA M
DATA Y
DATA Control signals of the Control Panel.
CLK
BACK LIGHT
BL +5 VDC
To Next Page
