2-24 Phaser 6130 Color Laser Printer Service Manual
Theory of Operation
Fuser
The Fuser fixes transferred toner onto the paper using heat and pressure and
feeds the paper before and after toner is fixed. The Fuser consists of the
following components: Heat Roller, Heater Lamp, Thermostat, Temperature
Sensor, Pressure Belt, Exit Roller, and Exit Sensor.
■ Exit Sensor
The Exit Sensor detects passage of printed pages after fusing on the
Actuator’s position changes.
