Xilinx Virtex-5 RocketIO GTP User Manual

Virtex-5 RocketIO GTP Transceiver User Guide www.xilinx.com 55
UG196 (v1.3) May 25, 2007
Package Placement Information
R
Figure 4-4: XC5VLX50T-FF1136, XC5VLX85T-FF1136, XC5VLX110T-FF1136, XC5VSX50T-FF1136, and XC5VSX95T-FF1136 GTP Placement (2 of 2)
AH3 MGTAVCCPLL_118AF4 MGTREFCLKP_118
XC5VLX50T: GTP_DUAL_X0Y1
XC5VLX85T: GTP_DUAL_X0Y1
XC5VLX110T: GTP_DUAL_X0Y2
XC5VSX50T: GTP_DUAL_X0Y1
XC5VSX95T: GTP_DUAL_X0Y2
AF3 MGTREFCLKN_118
AG3 MGTAVCC_118
AG4 MGTAVCC_118
AH1 MGTRXP1_118
AG1 MGTRXN1_118
AE3 MGTAVTTRX_118AE1 MGTRXP0_118
AF1 MGTRXN0_118
AD3 MGTAVTTTX_118
AJ3 MGTAVTTTX_118
AJ2 MGTTXP1_118
AH2 MGTTXN1_118
AD2 MGTTXP0_118
AE2 MGTTXN0_118
AB3 MGTAVCCPLL_114Y4 MGTREFCLKP_114
Power PinsRight Edge of the Die
XC5VLX50T: GTP_DUAL_X0Y2
XC5VLX85T: GTP_DUAL_X0Y2
XC5VLX110T: GTP_DUAL_X0Y3
XC5VSX50T: GTP_DUAL_X0Y2
XC5VSX95T: GTP_DUAL_X0Y3
Y3 MGTREFCLKN_114
AA3 MGTAVCC_114
AA4 MGTAVCC_114
AB1 MGTRXP1_114
AA1 MGTRXN1_114
W3MGTAVTTRX_114W1 MGTRXP0_114
Y1 MGTRXN0_114
AC3 MGTAVTTTX_114
V3MGTAVTTTX_114
AC2 MGTTXP1_114
AB2 MGTTXN1_114
V2 MGTTXP0_114
W2 MGTTXN0_114
AM4 MGTAVCCPLL_122AL5 MGTREFCLKP_122
XC5
VLX50T: GTP_DUAL_X0Y0
XC5VLX85T: GTP_DUAL_X0Y0
XC5VLX110T: GTP_DUAL_X0Y1
XC5VSX50T: GTP_DUAL_X0Y0
XC5VSX95T: GTP_DUAL_X0Y1
AL4 MGTREFCLKN_122
AJ4 MGTAVCC_122
AK5 MGTAVCC_122
AP3 MGTRXP1_122
AP2 MGTRXN1_122
AL3 MGTAVTTRX_122AL1 MGTRXP0_122
AM1 MGTRXN0_122
AK3 MGTAVTTTX_122
AM3 MGTAVTTTX_122
AN4 MGTTXP1_122
AN3 MGTTXN1_122
AK2 MGTTXP0_122
AL2 MGTTXN0_122
AM9 MGTAVCCPLL_126AL7 MGTREFCLKP_126
XC5VLX50T: Not Available
XC5VLX85T: Not Available
XC5VLX110T: GTP_DUAL_X0Y0
XC5VSX50T: Not Available
XC5VSX95T: GTP_DUAL_X0Y0
AM7 MGTREFCLKN_126
AL8 MGTAVCC_126
AM8 MGTAVCC_126
AP9 MGTRXP1_126
AP8 MGTRXN
1_126
AM6 MGTAVTTRX_126AP6 MGTRXP0_126
AP7 MGTRXN0_126
AM10 MGTAVTTTX_126
AM5 MGTAVTTTX_126
AN10 MGTTXP1_126
AN9 MGTTXN1_126
AN5 MGTTXP0_126
AN6 MGTTXN0_126
UG196_c4_04_012007
