Yamaha 40V - Removal and Installation Chart

7-4
BRKT
E
TILLER HANDLE
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
TILLER HANDLE DISASSEMBLY Follow the left “Step” for removal.
Tiller handle ass’y Refer to “TILLER HANDLE REMOVAL”.
1 Screw 4 6 × 16 mm
2 Screw 3 6 × 40 mm
3 Cover 1
4 Nut 1
5 Engine stop switch ass’y 1
6 Clamp 1
7 Cable clamp 2
8 Circlip 2
9 Throttle cable 1 Shorter cable
10 Shift cable 1 Longer cable
11 Bolt (with washer) 2 6 × 16 mm
12 Cable bracket 1
13 Screw (with washer) 2
14 Shift lever cover 1
15 Bolt (with washer) 4
16 Screw 1
17 Handle grip ass’y 1
18 Plain washer 1
19 Spring 1
20 Bushing 1
21 Bolt (with washer) 1
22 Shift lever 1
23 Bushing 1
24 Washer 1
25 Cotter pin 1
26 Friction knob 1
27 Nut 1
28 Bolt (with washer) 4 6 × 16 mm
29 Link ass’y 1
30 Friction piece 1
31 Grommet 1
32 Nylon nut 1
33 Plane washer 1
34 Bolt 1
NOTE:
Loosen the bolts temporarily.
NOTE:
When installing the bolts, tighten them
temporarily.
