7-10
BRKT
E
SHIFT ACTUATOR AND BOTTOM COWLING
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
SHIFT ACTUATOR AND BOT-
TOM COWLING REMOVAL
Follow the left “Step” for removal.
Power unit ass’y Refer to “POWER UNIT REMOVAL” in
chapter 5.
1 Shift actuator ass’y 1
2 Bolt (with washer) 2
3 Fitting plate ass’y 1
4 Grommet 1
5 PTT motor lead and trim sensor
lead
1 PTT model
6 Grommet 1
7 Bolt 4 6
×
30 mm
8 Plane washer 4
9 Bottom cowling ass’y 1
10 Seal rubber 1
11 Collar 4
12 Grommet 4
13 Grommet 1
SHIFT ACTUATOR ASS’Y
1
Plug screw 1
2
Spring 1
3
Ball 1
4
Clip 1
5
Clip 1
6 Bushing 1
7 Plane washer 1
8 Shift rod lever 1
9 Cotter pin 1
0 Plane washer 1
A Shift actuator 1
B Bushing 1
C Shift rod 1
Reverse the removal steps for installation.
NOTE:
Disconnect the leads from the clamp.
NOTE:
When installing the trim sensor leads and
PTT motor leads, align the taped end a
of the PTT motor leads with the end o
the grommet.
To Next Page
