4-8
FUEL
E
CARBURETOR
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
CARBURETOR DISASSEMBLY Follow the left “Step” for removal.
Carburetor ass’y Refer to “CARBURETOR REMOVAL”.
1 Drain screw 1
2 O-ring 1
3 Screw (with washer) 3 4 × 14 mm
4 Carburetor cover 1
5 Cover packing 1
6 Pilot adjusting screw 1
7 Spring 1
8 Stopping screw 1
Middle carburetor only
9 Spring 1
10 Screw (with washer) 4 4 × 14 mm
11 Float chamber 1
12 Float chamber packing 1
13 Screw 1 4 mm
14 Arm pin 1
15 Float 1
16 Needle valve 1
17 Needle valve clip 1
18 Valve seat 1
19 O-ring 1
20 Main jet 1
21 Main nozzle 1
22 Cap 1
23 Pilot jet 1
24 Carburetor body 1
Reverse the removal steps for installation.
CAUTION:
Do not damage the tip of the pilot scre
by over-tighten it.
NOTE:
The float is removed together with the
needle valve and the clip.
To Next Page
