ENRICHMENT CONTROL SYSTEM
ENRICHMENT CONTROL SYSTEM
1 Rectifier regulator
2 Lighting coil
3 Electrothermal valve
G : Green
G/W : Green/White
L : Blue
B : Black
LIGHTING COIL
Refer to “CHARGING SYSTEM”.
ELECTROTHERMAL VALVE
Refer to “PRIME STARTER” in chap-
ter 4.
RECTIFIER REGULATOR
Refer to “CHARGING SYSTEM”.
