7-26
BRKT
E
TILT UNIT REMOVAL
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
TILT UNIT REMOVAL Follow the left “Step” for removal.
Tilt up
1 PTT motor lead 1 PTT model
2 Band 3 PTT motor lead - Trim sensor lead
3 Bolt (with washer) 1 6 × 10 mm
4 Wire lead 1
5 Bolt (with washer) 1
6 Wire lead 1
7 Tilt rod ass’y 1
8 Nut 1
9 Plane washer 1
10 Stud bolt 1
11 Clamp bracket spacer ass’y 1
12 Bushing 2
13 Nut 1
14 Crip 2
15 Shaft pin 1
16 Tilt unit 1
17 Bushing 2
18 Collar 1
Reverse the removal steps for installation.
NOTE:
Turn the tilt support lever toward clamp
bracket and support the outboard.
