Yamaha 40V - Removal and Installation Chart; Service Points; Control Cable Inspection; Bushing Inspection

7-6
BRKT
E
TILLER HANDLE
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
35 Collar 1
36 Wave washer 1
37 Bracket 1
38 Steering handle 1
39 Bushing 2
Reverse the removal steps for installation.
SERVICE POINTS
Control cable inspection
1. Inspect:
●
Throttle cable
●
Shift cable
Kink/Fray/Stick → Replace.
Bushing inspection
1. Inspect:
●
Bushing
Wear/Crack/Damage → Replace.
Shift lever inspection
1. Inspect:
●
Shift lever
Wear/Crack/Damage → Replace.
Friction piece inspection
1. Inspect:
●
Friction piece
Wear/Crack/Damage → Replace.
Steering handle inspection
1. Inspect:
● Steering handle
Wear/Crack/Damage → Replace.
