5-10
POWR
E
FLYWHEEL MAGNETO AND MAGNETO BASE
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
FLYWHEEL MAGNETO AND
MAGNETO BASE REMOVAL
Follow the left “Step” for removal.
Recoil starter ass’y Refer to “RECOIL STARTER”.
1 Screw 1 6 × 40 mm
2 Screw 2 6 × 35 mm
3 Washer 3
4 Flywheel cover 1
5 Collar 3
6 Bolt (E model) 3 8 × 14 mm
7 Bolt (M model) 3 8 × 20 mm
8 Starter pulley (E model) 1
9 Starter pulley (M model) 1
10 Packing 1
11 Flywheel nut 1
12 Washer 1
13 Screw (with washer) 1 5 × 10 mm
14 Timing plate 1
15 Flywheel magneto 1
16 Woodruff key 1
17 Bolt 3 6 × 18 mm
18 Base ass’y 1
19 Gasket 1
Reverse the removal steps for installation.
