ELECTRICAL UNIT

REMOVAL AND INSTALLATION CHART

Step Procedure/Part name Q’ty Service points

ELECTRICAL UNIT DISASSEMBLY Follow the left “Step” for removal.

Electrical unit Refer to “ELECTRICAL UNIT REMOVAL”.

1 Fuse 1

2 Clamp 1

3 Bolt (with washer) 1

4 Clamp 1

5 Bolt (with washer) 1

6 Rectifier regurator 1

7 Nut 2

8 Spring washer 1

9 Bracker 1

10 Relay holder 1

11 Starter relay 1

12 Bolt (with washer) 2 PTT model

13 Bolt (with washer) 1

14 Bolt (with washer) 2

15 PTT relay 1

16 Bracket 1

17 Collar 3

18 Grommet 3

Reverse the removal steps for installation.
