8-24
–+
ELEC
E
STARTER MOTOR
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
STARTER MOTOR DISASSEMBLY Follow the left “Step” for removal.
Starter motor ass’y Refer to “ELECTRICAL UNIT REMOVAL”
in chapter 5.
1 Clip 1
2 Pinion stopper 1
3 Spring 1
4 Pinion 1
5 Through bolt 2
6 Front cover 1
7 Washer 1 25 × 1.0 mm
8 Washer 2 25 × 0.15 mm
9 Washer 1 25 × 2.0 mm
10 Starter ass’y 1
11 Armature ass’y 1
12 Washer 1 16 × 0.25 mm
13 Nut 1
14 Spring washer 1
15 Plain washer 1
16 Bushing 1
17 O-ring 1
18 Bushing 1
19 Screw 2
20 Brush holder 1
21 Brush (+) 1
22 Rear cover 1
23 O-ring 2
Reverse the removal steps for installation.
NOTE:
Using a pry bar, pry off the clip.
