7-34
BRKT
E
PUMP HOUSING
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
PUMP HOUSING DISASSEMBLY Follow the left “Step” for removal.
Pump housing ass’y Refer to “TILT CYLINDER, PUMP HOUS-
ING AND MOTOR REMOVAL”.
1 Socket bolt 4
2 Gear pump 1
3 O-ring 2 8.5 × 5.5 mm
4 Bolt (with washer) 4
5 Bottom cover 1
6 O-ring 1 78.5 × 74.5 mm
7 Clip 1
8 Inlet hose 1 55 ~ 59 mm
9 Screw 2
10 Retaining plate 1
11 Spring 1 8.8 × 4.3 mm
12 Valve support pin 1
13 Valve seat 1
14 Spring 1 8.8 × 21.8 mm
15 Valve seat 1
16 Valve support pin 1
17 Valve seat 1
18 O-ring 1 13.7 × 10.7 mm
19 Filter 1
20 Main valve 2
21 O-ring 2 17.1 × 12.3 mm
22 O-ring 2 14.5 × 11.5 mm
23 Shuttle piston 1
24 O-ring 1 12.6 × 8.8 mm
25 Circlip 1
26 Valve body 1
27 O-ring 1 10.6 × 6.8 mm
28 O-ring 1 9.6 × 5.8 mm
29 Valve seal 1
30 Spring 1 6.2 × 27.0 mm
31 Pin 1
32 Valve seal 1
33 Circlip 1
34 Manual valve 1
35 Ball 1 3.97 mm
36 O-ring 1 22.6 × 17.8 mm
37 Pump housing 1
Reverse the removal steps for installation.
