1-8
GEN
INFO
E
SPECIAL TOOLS
REMOVAL AND INSTALLATION
Tool name
Tool No.
Use for:
USA and
Canada
a
Except for
USA and
Canada
b
1
Small end bearing
needle installer
YB-06106 90890-06526 Small end
2 Bearing separator YB-06219 90890-06534
Crank shaft
bearing
Reverse gear
bearing
Forward
gear inner
bearing
3 Flywheel holder YB-06139 90890-06522 Flywheel
4 Flywheel puller YB-06117 90890-06521 Flywheel
5 Stopper guide plate N.A. 90890-06501
Propeller
shaft housing
Reverse gear
bearing
Drive shaft
outer bearing
6 Bearing housing puller YB-06234 90890-06503 Propeller shaft housing
7 Center bolt N.A. 90890-06504 Propeller shaft housing
8 Universal puller YB-06117 N.A. Propeller shaft housing
9 Oil seal installer YB-06168 N.A. Propeller shaft oil seal
10 Needle bearing remover YB-06112 90890-06614
Propeller shaft
needle bearing
11 Needle bearing installer YB-06111 90890-06614
Propeller shaft
needle bearing
12
Bearing outer race puller
clow
N.A. 90890-06535 Reverse gear bearing
13 Stopper guide stand N.A. 90890-06538
Reverse gear
bearing
Forward
gear outer
bearing
14 Slide hammer set YB-06096 N.A.
Reverse gear
bearing
Drive shaft
outer bearing
Forward
gear outer
bearing
15 Pinion nut wrench N.A. 90890-06505 Pinion nut
16 Socket adapter N.A. 90890-06506 Pinion nut
17 Drive shaft holder YB-06079 90890-06517 Pinion nut
18
Needle bearing attach-
ment
YB-06063 90890-06614 Drive shaft needle bearing
19
Drive shaft needle bear-
ing depth stop
YB-34473 N.A. Drive shaft needle bearing
20 Bearing installer YB-06167 90890-06628 Drive shaft oil seal
21 Bearing installer YB-06110 90890-06627 Drive shaft outer bearing
22 Bearing installer YB-06270-A 90890-06640 Forward gear inner bearing
